JH6000A-4 Decomposition product detector

recommendation index：

Detection components, high accuracy, good stability

Portable design, fast testing, low air consumption, environmentally friendly

Automatic flow control, efficient and accurate, effectively reducing sample gas emissions

Expert systems provide intelligent diagnostics

Detection of the main products of cracking of insulating materials inside SF6 electrical equipment: SO₂, SOF₂, H₂S, CO, HF

name	component	parameter
minimum detectable quantity	SO₂+SOF₂、H₂S、HF	≤0.1μL/L
minimum detectable quantity	CO	≤0.5μL/L
precision	SO₂+SOF₂、H₂S、HF	measurement value ≤ 10 μL/L, error ≤ ± 0.5 μL/L measured value > 10 μL/L, error≤ ± 5%.
precision	CO	measurement value ≤ 50 μL/L, error≤ ± 2.0 μL/L measurement value > 50 μL/L, error ≤ ± 4%
repeatability	SO₂+SOF₂ 、H₂S、HF	measured value ≤ 10 μL/L, ≤ 0.2 μL/L measured value > 10 μL/L, ≤ 2%
repeatability	CO	measured value ≤ 50 μL/L, ≤ 1.5 μL/L measured values > 50 μL/L~ 1000 μL/L, ≤ 3%
range	SO₂+SOF₂	0～100μL/L,0～2000μL/L
	H₂S	0～100μL/L
	HF	0～20μL/L
	CO	0～1000μL/L
